BELAR AM RF DISTRIBUTION AMPLIFIER



DESCRIPTION

The Belar AMDA-1 is a wideband loss-less active AM RF SPLITTER for distributing the AM signal from a single LP-1A active loop antenna to up to twelve receivers.



SPECIFICATIONS

Input                                   50 ohm BNC

Phantom Power Fused                     +12 VDC

Outputs                                 (12) 75 ohm f connectors

Frequency Response                      0.4 to 5 Mhz ± 0.5 db

Power Consumption                       10 watts, 100-240 V, 50-60 Hz

Dimensions                              1 3/4"H ´ 19"W ´ 8" D (EIA rack mount)

Shipping Weight                         8 lbs. (3.8 kg)

Printer-friendly version (This is in PDF format and needs to be viewed in Abode Acrobat Reader.
If you don't have a copy of the Reader, you can download one for free from Adobe.)

© Copyright 2000 Belar Electronics Laboratory, Inc. All rights reserved.
Specifications subject to change without prior notice.
